Pressure sensor BMP581

Highest performance. Small size. Accurate.

BMP581

Barometric pressure sensor

The BMP581 is the new benchmark in the field of barometric pressure sensors and impresses with its enormous accuracy. This enables endless and new use cases such as fitness tracking where accurate altitude change is key. The low power and low noise 24 bit absolute barometric pressure sensor significantly improved its accuracy compared to previous generations at smallest size. It offers outstanding design flexibility, providing a single package solution that customers can easily integrate into a multitude of existing and upcoming devices such as GPS modules, wearables, hearables, smart home, IoT and industrial products.

High performance barometric pressure sensor #BMP581

Technical data

Parameter Technical data
Parameter
Package dimensions
Technical data
2.0 x 2.0 x 0.75 mm³ metal lid LGA
Parameter
Operating range
(full accuracy)
Technical data
Pressure: 300 … 1250 hPa
Parameter
Supply voltage VDDIO
Technical data
1.08 V … 3.6 V
Parameter
Supply voltage VDD
Technical data
1.65 V … 3.6 V
Parameter
Interface
Technical data
I²C (up to 1.0 MHz), I3C, and SPI (3 and 4 wire, up to 10 MHz)
Parameter
Average typical current consumption (1 Hz data rate)
Technical data
1.3 µA @ 1 Hz pressure and temperature, 0.5 µA in deep standby mode
Parameter
Absolute accuracy
P=300 ...1100 hPa
(T=-5 … 65°C)
Technical data
±30 Pa
Parameter
Relative accuracy
Pressure (typ.)
P=700…1100 hPa
(T=15 … 55°C)
Technical data

±6 Pa
(equivalent to ±0.5 m)
Parameter
Noise in pressure
lowest bandwidth, highest resolution
Technical data
0.08 Pa
Parameter
Temperature coefficient offset (typ.)
P=300 hPa ...1100 hPa
(T=-5 ... 65°C)
Technical data
± 0.5 Pa/K
Parameter
Long-term drift
(12 months)
Technical data
±0.1 hPa
Parameter
Solder drift
Technical data
±0.3 hPa
Parameter
Maximum sampling rate
Technical data
480 Hz (continous mode)

Order

Documents

Download white paper


To receive the white paper, enter your contact details so that we can send you a download link.

Download white paper


To receive the white paper, enter your contact details so that we can send you a download link.

Download white paper


To receive the white paper, enter your contact details so that we can send you a download link.

Download white paper


To receive the white paper, enter your contact details so that we can send you a download link.

Download white paper


To receive the white paper, enter your contact details so that we can send you a download link.

Software

Download white paper


To receive the white paper, enter your contact details so that we can send you a download link.

White paper: Wi-Fi 6E/7 – Vertical location service

building vertifal location detection WiFi 6E/7

White paper: Wi-Fi 6E/7 – Vertical location service

Whether at home, in the office, or on the go, we rely on Wi-Fi to connect devices wirelessly in countless places. Wi-Fi 6E/7 has been adopted by many countries to reduce the growing demand for congestion, improve bandwidth and increase speed. Wi-Fi 6E/7 providers are required by FCC regulation FCC-20-51 to report to the AFCs the height above ground of Wi-Fi APs operating at the higher SP power level and in 6 GHz spectrum. For access point installers and system operators, a solution that provides an automated method for recording the vertical location of access points is needed to meet the FCC requirement in a cost-effective manner. One way to address this challenge is to use a barometric pressure-based solution that is able to provide the exact value of the height above the ground for each Wi-Fi AP. Learn more about how our sensing solutions BMP581 and BMP580 can be used for this use case and download the whitepaper presented by NextNav and Bosch Sensortec.

Applications and solutions

Woman jogging.

Wearables & hearables

Smartwatches, wristbands, smart clothes and hearables: whether supporting your fitness through calorie counting or helping you orient yourself through navigation, our accurate and ultra-low power sensing solutions turn a regular wearable into your daily companion!

Bosch Sensortec

Industrial applications

What comes to your mind if you think about industrial applications? Probably you think of production, machinery and factory applications. Incorporating also home appliances, building automation, logistics and others, Bosch Sensortec goes far beyond this understanding and provides MEMS sensing solutions that target the specific needs of the industrial electronics market.

Man and woman looking at a smartphone

Smart home

Imagine you get up on a cold day and the bathroom is heated the way you prefer it. When you leave home, sensor-activated intrusion detection gives you peace of mind during the day. Our sensing solutions enable many smart home applications, enhancing your well-being.
