On the one hand, this product category contains the family of intelligent sensor hubs. These are smart inertial sensors, with an integrated MEMS sensor hub and a freely programmable microcontroller. Specifically designed for always-on sensing applications in mobile devices and wearables. It offers you a flexible, low power solution for motion sensing and data processing. Software included! Programmable! Extendable! Bringing you the full Android sensor stack inside your devices – even without having an Android OS environment. On the other hand, the new family of application specific sensor nodes (ASSNs) provides you an intelligent 9-axis “Absolute Orientation Sensor”, including inertial- and magnetic sensors, a microcontroller and full data fusion. Everything under one roof – in one single tiny package.



ASSNs




BMF055

The BMF055 is an extension of the ASSNs family implementing a custom programmable 9-axis motion sensor which includes sensors and a microcontroller in a single package."

BNO055

The BNO055 is a MEMS sensor in the family of ASSNs implementing an intelligent 9-axis absolute orientation sensor, which includes sensors and sensor fusion in a single package.



BNO070 (under phase-out)

Not recommended for new design-ins

BNO080

The BNO080 is a 9-axis System in Package (SiP) which enables rapid development of sensor-enabled Augmented Reality (AR), Virtual Reality (VR), Robotics and IoT devices. It features a high-performance accelerometer, magnetometer, and gyroscope with a low-power 32-bit ARM Cortex M0+ MCU in a small package. Hillcrest’s Freespace® sensor hub software is pre-integrated.







Smart hubs




BHI160BP

The BHI160BP is an application specific upgrade of the BHI160 family and comes with Pedestrian Dead Reckoning (PDR) Algorithm that allows Pedestrian Position Tracking at a fraction of the power consumption of GNSS only solutions.

BHI260

The BHI260 is a family of ultra-low power smart hubs consisting of Bosch Sensortec’s new, programmable 32-bit microcontroller (Fuser2), a state-of-the-art 6-axis IMU and a powerful software framework containing pre-installed sensor fusion and other sensor processing software within a small 44 pad LGA package.



BHA260

The BHA260 is a family of ultra-low power smart hubs consisting of Bosch Sensortec’s new, programmable 32-bit microcontroller (Fuser2), a state-of-the-art 3-axis accelerometer and a powerful software framework containing pre-installed sensor fusion and other sensor processing software within a small 22 pad LGA package.

BHI160

The BHI160 is a small, low-power smart-hub with an integrated three axis gyroscope plus an integrated three axis accelerometer plus a programmable microcontroller. Containing pre-installed software and algorithms for activity recognition it is specifically designed to enable always-on motion sensing. It perfectly matches smartphones, wearables or any other application which requires highly accurate, real-time motion data at very low power consumption.



BHA250

The BHA250 is a small, low-power smart-hub with an integrated three axis accelerometer plus a programmable microcontroller. Containing pre-installed software and algorithms for activity recognition it is specifically designed to enable always-on motion sensing. It perfectly matches smartphones, wearables or any other application which requires highly accurate, real-time motion data at very low power consumption.
