    BMA456

    The BMA456 is an ultra-small, triaxial, low-g high performance acceleration sensor with digital interfaces, aiming for low-power wearable and hearable applications. Featuring 16-bit digital resolution and smart features for wearables and hearables, the BMA456 allows low-noise measurement of accelerations in three perpendicular axes. The sensor is available with two different feature sets: The wearable feature set for BMA456 integrates gesture recognition such as wrist tilt, tap and double tap and enables plug ’n’ play step counting and activity recognition. The hearable feature set integrates tap, double tap and triple tap for intuitive user interaction, no-motion and motion for optimized power management as well as activity recognition and step counting for fitness applications. The superior temperature behavior of BMA456 facilitates accurate measurements over changing temperatures. The reduced height of only 0.65 mm is ideally suited for wearable and hearable devices.

    Applications

    - Step counting and step detection

    - Wake up display on wrist tilt in wearables

    - Low-power tap, double tap and triple tap in hearables

    - Advanced gesture recognition

    - Activity recognition/tracking

    - Advanced power management: motion/no-motion

    - In-ear/ out-of-ear detection




    Wearable Applications

    A wristband personal alarm clock will make sure that not only will you get up on time but also in sync with your natural biorhythm. A smartwatch can improve your health by detecting poor air quality in your environment. Smart fitness wear can improve the efficiency of your workout by measuring your speed and calorie consumption. What do all these wearable applications have in common? They are made possible by the almost invisible MEMS sensors and clever sensor solutions.

    discover the application

    watch the video








    Other sensors in the same category



    BMA400

    The BMA400 is an ultra-small and ultra-low power acceleration sensor for wearables and IoT applications.

    BMA421

    The BMA421 is an small acceleration sensor with a footprint of 2 x 2mm² and a 12 bit digital resolution.

    BMA423

    The BMA423 is an ultra-small, low-g acceleration sensor with 12 bit digital resolution for wearable devices.

    BMA222E

    The BMA222E is an small acceleration sensor with a footprint of 2 x 2mm² and a 8 bit digital resolution.



    BMA250E

    The BMA250E with its 2 x 2 mm² footprint and a 10 bit digital resolution allows low-noise measurement of accelerations in 3 perpendicular axes.

    BMA255

    With its small footprint of only 2 x 2mm² the BMA255 is unique in the class of low-noise, 12 bit digital acceleration sensors.

    BMA253

    The ultra-small package of only 2 x 2mm² and the interfaces of the BMA253 have been defined to match a multitude of hardware requirements.

    BMA423

    The BMA421 is an ultra-small, low-g acceleration sensor with 12 bit digital resolution for wearable devices.



    BMA455

    With its embedded intelligence BMA455 is unique in the class of consumer grade accelerometers for smartphones, wearable devices and toys and gadgets.

    BMA280

    The BMA280 is an advanced, triaxial, low-g acceleration sensor with digital interfaces, aiming for low-power consumer electronics applications. The sensor has a footprint of 2 x 2mm² and a 14 bit digital resolution.


  • Technical data
    Parameter Technical data
    Digital resolution 16 bit
    Resolution
    (in ±2g range)
    0.06 mg
    Measurement ranges
    (programmable)
    ±2 g, ±4 g, ±8 g, ±16 g
    Sensitivity (calibrated) ±2 g: 16384 LSB/g
    ±4 g: 8192 LSB/g
    ±8 g: 4096 LSB/g
    ±16 g: 2048 LSB/g
    Zero-g offset (typ., over life-time) ±20 mg
    Noise density (typ.) 120 µg/vHz
    Bandwidths (programmable) 1600 Hz ... 1.5 Hz
    Digital inputs/outputs SPI & I2C,
    2x digital interrupt pins
    Supply voltage (VDD) 1.62 … 3.6 V
    I/0 supply voltage (VDDIO) 1.2 … 3.6 V
    Temperature range -40 … +85°C
    Current consumption
    - full operation
    - low-power mode
    150 μA
    13 μA (at 50Hz data rate)
    FIFO data buffer 1 kB
    LGA package 2 x 2 x 0.65 mm³
    Shock resistance 10,000 g x 200 µs
