Smart sensor: BHI360

Small. Programmable. Low-power.

Order now

BHI360

Programmable smart sensor combining accelerometer, gyroscope and fusion software

BHI360 is a programmable IMU-based sensor system combining a gyroscope with an accelerometer that enables full customization. The integrated sensor fusion library enables 3D audio with head orientation for personalized sound experiences as well as simple gesture recognition. It can be used in wearables and hearables, smartphones and tablets, smart devices and more.

The sensor is provided in a compact 20-pin LGA package measuring 2.5 x 3 x 0.95 mm³. This means it is 50% smaller than its previous generation, and that it is the smartest programmable IMU sensor in the market. BHI360 is a highly integrated, ultra-low power, smart 6-axis IMU consisting of a 32-bit programmable microcontroller. In addition, it consists of an ultra-low power microprocessor, including pre-installed sensor fusion software and algorithms in a single package.

Head orientation for 3D Audio

Gesture detection and activity

Human Machine Interaction

Technical data

Parameter	Technical data
Parameter Operating voltage	Technical data 1.8 V
Parameter Current consumption Fuser2 (running CoreMark) Long Run mode (20 MHz) Turbo mode (50 MHz) Sensor Fusion (Hub+IMU) operation (calculating Game Rotation Vector) 800 Hz ODR 100 Hz ODR Standby current	Technical data 950 μA 2.8 mA 1.2 mA 1.0 mA 8 μA
Parameter Sensor Fusion Performance Static accuracy (Heading, Pitch, Roll) Dynamic accuracy (Heading, Pitch, Roll) Calibration time Orientation stabilization time	Technical data 2, 2, 2 degrees 7, 2, 2 degrees <1 second 0.2 seconds

Out of stock Click here to order

Out of stock Click here to order

Out of stock Click here to order

Out of stock Click here to order

Download white paper

To receive the white paper, enter your contact details so that we can send you a download link.

Yes, I would like to receive marketing information concerning Bosch Sensortec products from Bosch Sensortec GmbH via e-mail on the basis of my personal interests and for this purpose I agree to the usage and storage of the data I have provided. I have read the data protection notice and acknowledge that I can withdraw my consent at any time with effect for the future.*

* These fields are required

Flyer

BST-BHI360-FL000

Download white paper

To receive the white paper, enter your contact details so that we can send you a download link.

* These fields are required

Datasheet

BST-BHI360-DS000

Download white paper

To receive the white paper, enter your contact details so that we can send you a download link.

* These fields are required

Shuttle board flyer

BST-BHI360-SF000

Download white paper

To receive the white paper, enter your contact details so that we can send you a download link.

* These fields are required

Handling, soldering & mounting instructions

BST-MIS-HS001
